ELNet GR/PQ - Current in Neutral Line

48
4 In order to view the readings in online graphical
mode press on the "Enter" button.
You can reset the Peak values by using the “CLEAR” button.
Read the Frequency in Line 1, Line 2, Line3
5.3 Current in Neutral Line
ElNet GR - By using the Vector value of L1/2/3 Current
Lines calculates the Current in the Neutral Line .
ElNet PQ – measures the Neutral Line current via additional
current transformer.
If the reading for neutral line is “0” (i.e. there is no current in the
neutral line), then either there is no current in system,
OR
the current for all three phases is balanced.
To display Current in the Neutral Line:
1 From Main Menu scroll to Current & Voltage.
2 Click “Enter” the Current & Voltage screen appears
as described in section 5.1.
5 Click “F3” - “TABLE”.
