ELNet GR/PQ - Mechanical Mounting

15
2.2 Mechanical mounting
To Mount the ElNet Energy & Powermeter
Choose a suitable location, and prepare a rectangular hole
according to the dimensions shown in Figure 2.1
Figure 2.1. Panel Cutout
Do not mount the ElNet Energy &
Powermeter too close to any main electrical
conductors.
Allow sufficient space to carry out
maintenance to the back of the ElNet
Energy & Powermeter
NOTE!
!
Width
138 mm
Height
138 mm
