ELNet GR/PQ - Page 60

60
To display Harmonics Current Bar Graph
1 Click “F2”, the Harmonic Current Bar Graph
screens appears.
Figure 5.17. Harmonic Current Bar Graph
2 Press “F3” to change Harmonics Current Bar
Graph to Line 1, Line 2, Line 3, Neutral Line (L0)
and Lines 1,2,3 together.
