Affinity User Guide 13
Issue Number: 5 www.controltechniques.com
For size 1 to 6 standard drives, size 1 to 3 E12/54 drives, and size 1 to 3 E12/E66 drives, the continuous current ratings given are for maximum 40°C
(104°F),1000m altitude and 3.0kHz switching. For size 4 to 6 E12/54 drives, the continuous current ratings given are for maximum 35°C
(95°F),1000m altitude and 3.0kHz switching. For further information refer to section 12.1.1 Power and current ratings (Derating for switching
frequency and temperature) on page 228.
Table 2-3 575V Drive ratings (500V to 575V ±10%)
The power ratings above for model size 4 and larger are for the 690V drives when used on a 500V to 575V supply.
Table 2-4 690V Drive ratings (500V to 690V ±10%)
Model
Maximum continuous
output current
Nominal power
at 575V
Motor power
at 575V
Peak current
AkWhpA
3501 5.4 3.0 3.0 5.9
3502 6.1 4.0 5.0 6.7
3503 8.4 5.5 7.5 9.2
3504 11 7.5 10 12.1
3505 16 11 15 17.6
3506 22 15 20 24.2
3507 27 18.5 25 29.7
4603 36 22 30 39.6
4604 43 30 40 47.3
4605 52 37 50 57.2
4606 62 45 60 68
5601 84 55 75 92
5602 99 75 100 108
6601 125 90 125 137
6602 144 110 150 158
Model
Maximum continuous
output current
Nominal power
at 690V
Motor power
at 690V
Peak current
AkWhpA
4601 22 18.5 25 24.2
4602 27 22 30 29.7
4603 36 30 40 39.6
4604 43 37 50 47.3
4605 52 45 60 57.2
4606 62 55 75 68.2
5601 84 75 100 92
5602 99 90 125 108
6601 125 110 150 137
6602 144 132 175 158
3
4
55
56
4
55
56
