242 Affinity User Guide
www.controltechniques.com Issue Number: 5
Cable sizes are from IEC60364-5-52:2001 table A.52.C with correction
factor for 40°C ambient of 0.87 (from table A52.14) for cable installation
method B2 (multicore cable in conduit).
Only PVC insulated cables should be used.
Cable size may be reduced if a different installation method is used, or if
the ambient temperature is lower.
The recommended cable sizes above are only a guide. The mounting
and grouping of cables affects their current-carrying capacity, in some
cases smaller cables may be acceptable but in other cases a larger
cable is required to avoid excessive temperature or voltage drop. Refer
to local wiring regulations for the correct size of cables.
Table 12-26 Size 4 and larger input current, fuse and cable size ratings
Cable sizes are from IEC60364-5-52:2001 table A.52.C with correction
factor for 40°C ambient of 0.87 (from table A52.14) for cable installation
method B2 (multicore cable in conduit).
Only PVC insulated cables should be used.
Cable size may be reduced if a different installation method is used, or if
the ambient temperature is lower.
The recommended cable sizes above are only a guide. The mounting
and grouping of cables affects their current-carrying capacity, in some
cases smaller cables may be acceptable but in other cases a larger
cable is required to avoid excessive temperature or voltage drop. Refer
to local wiring regulations for the correct size of cables.
Inrush current
The drive will have an inrush current during power-up, the peak inrush is
limited to the value shown below:
BA120X 18 A peak
BA140X 35 A peak
BA220X 12 A peak
BA240X 24 A peak
BA320X 8 A peak
BA340X 14 A peak
BA350X 18 A peak
For sizes 4 to 6, the inrush current is limited by a controlled rectifier to
below the rated current of the drive.
The inrush current for all drives after a brown-out can be larger than the
power-up inrush.
NOTE
Model
Typical input
current
Maximum
input current
Fuse option 1
Fuse option 2
semiconductor fuse in series
with HRC fuse or breaker
Cable size
IEC class
gR
North
America:
Ferraz HSJ
HRC
IEC class gG
UL class J
Semi-
conductor
IEC class aR
EN60204 UL508C
AAAAA A
Input
mm
2
Output
mm
2
Input
AWG
Output
AWG
BA 4201 62.1 68.9 100 90 90 160 25 25 3 3
BA 4202 72.1 78.1 100 100 100 160 35 35 3 3
BA 4203 94.5 99.9 125 125 125 200 70 70 1 1
BA 5201 116 142 200 175 160 200 95 95 2/0 2/0
BA 5202 137 165 250 225 200 250 120 120 4/0 4/0
BA 4401 61.2 62.3 80 80 80 160 25 25 3 3
BA 4402 76.3 79.6 100 110 100 200 35 35 2 2
BA 4403 94.1 97.2 125 125 125 200 70 70 1 1
BA 5401 126 131 200 175 160 200 95 95 2/0 2/0
BA 5402 152 156 250 225 200 250 120 120 4/0 4/0
BA 6401 224 241 315 300 250 315 2 x 70 2 x 70 2 x 2/0 2 x 2/0
BA 6402 247 266 315 300 300 350 2 x 95 2 x 95 2 x 4/0 2 x 4/0
BA 4601 23 26.5 63 60 32 125 4 4 10 10
BA 4602 26.1 28.8 63 60 40 125 6 6 8 8
BA 4603 32.9 35.1 63 60 50 125 10 10 8 8
BA 4604 39 41 63 60 50 125 16 16 6 6
BA 4605 46.2 47.9 63 60 63 125 16 16 6 6
BA 4606 55.2 56.9 80 60 63 125 25 25 4 4
BA 5601 75.5 82.6 125 100 90 160 35 35 2 2
BA 5602 89.1 94.8 125 100 125 160 50 50 1 1
BA 6601 128 138 200 200 200 200 2 x 50 2 x 50 2 x 1 2 x 1
BA 6602 144 156 200 200 200 200 2 x 50 2 x 50 2 x 1 2 x 1
NOTE
NOTE
