Table 13-3 Serial communications look-up table
No. Trip No. Trip No. Trip
1
UV 40 to 89 t040 to t089 182 C.Err
2
OV 90 UP div0 183 C.dAt
3
OI.AC 91 UP PAr 184 C.FULL
4
OI.br 92 UP ro 185 C.Acc
5
PS 93 UP So 186 C.rtg
6
Et 94 UP ovr 187 C.TyP
7
O.SPd 95 UP OFL 188 C.cPr
8
PS.10V 96 UP uSEr 189 Reserved
9
PS.24V 97 UP udF 190 Reserved
10 Reserved 98
UP ACC 191 Reserved
11
tunE1 99 t099 192 Reserved
12
tunE2 100 193 Reserved
13
tunE3 101 t101 194 Reserved
14 Reserved 102
Oht4.P 195 Reserved
15 Reserved 103
OIbr.P 196 Reserved
16 Reserved 104
OIAC.P 197 Reserved
17
tunE7 105 Oht2.P 198 Reserved
18
tunE 106 OV.P 199 DESt
19
It.br 107 PH.P 200 SL1.HF
20
It.AC 108 PS.P 201 SL1.tO
21
O.ht1 109 OIdC.P 202 SL1.Er
22
O.ht2 110 Unid.P 203 SL1.nF
23
O.CtL 111 ConF.P 204 SL1.dF
24
th 112 to 160 t112 to t160 205 SL2.HF
25
thS 161 Reserved 206 SL2.tO
26
O.Ld1 162 Reserved 207 SL2.Er
27
O.ht3 163 Reserved 208 SL2.nF
28
cL2 164 Reserved 209 SL2.dF
29
cL3 165 Reserved 210 SL3.HF
30
SCL 166 Reserved 211 SL3.tO
31
EEF 167 Reserved 212 SL3.Er
32
PH 168 to 174 t168 to t174 213 SL3.nF
33
rS 175 C.Prod 214 SL3.dF
34
PAd 176 Reserved 215 SL.rtd
35
CL.bit 177 C.boot 216 t216
36
SAVE.Er 178 C.bUSY 217 to 232 HF17 to HF32
37
PSAVE.Er 179 C.Chg
38 LOAD 180 C.OPtn
39 Reserved 181
C.RdO
