Emerson Affinity User Manual

Safety
Information
Product
Information
Mechanical
Installation
Electrical
Installation
Getting
Started
Basic
parameters
Running
the motor
Optimization
SMARTCARD
operation
PC tools
Advanced
parameters
Technical
Data
Diagnostics
UL Listing
Information
72 Affinity User Guide
www.controltechniques.com Issue Number: 5
Table 4-3 Size 1 to 3 input current, fuse and cable size ratings (European)
Table 4-4 Size 1 to 3 input current, fuse and cable size ratings (USA)
Fuses
The AC supply to the drive must be installed with suitable protection against overload and short-circuits. Table 4-3, Table 4-4 and
Table 4-5 show recommended fuse ratings. Failure to observe this requirement will cause risk of fire.
WARNING
Model
Typical
input
current
A
Maximum
continuous
input current
A
Fuse
rating
IEC gG
A
Cable size
EN60204
Input
mm
2
Output
mm
2
BA1201 7.1 9.5 10 1.5 1.0
BA1202 9.2 11.3 12 1.5 1.0
BA1203 12.5 16.4 20 4.0 1.0
BA1204 15.4 19.1 20 4.0 1.5
BA2201 13.4 18.1 20 4.0 2.5
BA2202 18.2 22.6 25 4.0 4.0
BA2203 24.2 28.3 32 6.0 6.0
BA3201 35.4 43.1 50 16 16
BA3202 46.8 54.3 63 25 25
BA1401 4.1 4.8 8 1.0 1.0
BA1402 5.1 5.8 8 1.0 1.0
BA1403 6.8 7.4 8 1.0 1.0
BA1404 9.3 10.6 12 1.5 1.0
BA1405 10 11 12 1.5 1.0
BA1406 12.6 13.4 16 2.5 1.5
BA2401 15.7 17 20 4.0 2.5
BA2402 20.2 21.4 25 4.0 4.0
BA2403 26.6 27.6 32 6.0 6.0
BA3401 34.2 36.2 40 10 10
BA3402 40.2 42.7 50 16 16
BA3403 51.3 53.5 63 25 25
BA3501 5.0 6.7 8 1.0 1.0
BA3502 6.0 8.2 10 1.0 1.0
BA3503 7.8 11.1 12 1.5 1.0
BA3504 9.9 14.4 16 2.5 1.5
BA3505 13.8 18.1 20 4.0 2.5
BA3506 18.2 22.2 25 4.0 4.0
BA3507 22.2 26.0 32 6.0 6.0
Model
Typical
input
current
A
Maximum
continuous
input current
A
Fuse rating
Class CC or
J <30A
Class J >30A
A
Cable size
UL508C
Input
AWG
Output
AWG
BA1201 7.1 9.5 10 14 18
BA1202 9.2 11.3 15 14 16
BA1203 12.5 16.4 20 12 14
BA1204 15.4 19.1 20 12 14
BA2201 13.4 18.1 20 12 14
BA2202 18.2 22.6 25 10 10
BA2203 24.2 28.3 30 8 8
BA3201 35.4 43.1 45 6 6
BA3202 46.8 54.3 60 4 4
BA1401 4.1 4.8 8 16 22
BA1402 5.1 5.8 8 16 20
BA1403 6.8 7.4 10 16 18
BA1404 9.3 10.6 15 14 16
BA1405 10 11 15 14 14
BA1406 12.6 13.4 15 14 14
BA2401 15.7 17 20 12 14
BA2402 20.2 21.4 25 10 10
BA2403 26.6 27.6 30 8 8
BA3401 34.2 36.2 40 6 6
BA3402 40.2 42.7 45 6 6
BA3403 51.3 53.5 60 4 4
BA3501 5.0 6.7 10 16 18
BA3502 6.0 8.2 10 16 16
BA3503 7.8 11.1 15 14 14
BA3504 9.9 14.4 15 14 14
BA3505 13.8 18.1 20 12 14
BA3506 18.2 22.2 25 10 10
BA3507 22.2 26.0 30 8 8
