Affinity User Guide 235
Issue Number: 5 www.controltechniques.com
Table 12-10 Losses @ 40°C (104°F) ambient for size 1 and 2 drives with IP54 insert and standard fan installed
Model
Drive losses (W) taking into consideration any current derating for the given conditions
3kHz 4kHz 6kHz 8kHz 12kHz 16kHz
BA1201 73 75 78 82 89 96
BA1202 85 87 91 96 104 113
BA1203 107 110 116 118
BA1204 118
BA2201 155 161 173 186 210 235
BA2202 210 218 234 237
BA2203 237
BA1401 66 69 77 85 101 116
BA1402 74 78 88 97 116 118
BA1403 84 90 101 112 118
BA1404 102 109 118
BA1405 118
BA1406 118
BA2401 186 202 234 237
BA2402 237
BA2403 237
