234 Affinity User Guide
www.controltechniques.com Issue Number: 5
Table 12-9 Losses @ 40°C (104°F) ambient for size 1 to 6 standard, size 1 to 3 E12/E54 drives and size 1 to 3 E12/E66 drives
Model
Drive losses (W) taking into consideration any current derating for the given conditions
Nominal rating
3kHz 4kHz 6kHz 8kHz 12kHz 16kHz
kW hp
BA1201 1.1 1.5 73 75 78 82 89 96
BA1202 1.5 2.0 85 87 91 96 104 113
BA1203 2.2 3.0 107 110 116 121 132 144
BA1204 3.0 3.0 118 122 129 137 153 169
BA2201 4.0 5.0 155 161 173 186 210 235
BA2202 5.5 7.5 210 218 234 250 282 314
BA2203 7.5 10 272 282 302 320 315
BA3201 11 15 331 347 380 412 477
BA3202 15 20 431 451 492 532 551
BA4201 18.5 25 517 541 589 637
BA4202 22 30 611 639 694 750
BA4203 30 40 810 845 916 987
BA5201 37 50 1250 1340 1540 1730
BA5202 45 60 1500 1620 1840 1910
BA1401 1.1 1.5 66 69 77 85 101 116
BA1402 1.5 2.0 74 78 88 97 116 135
BA1403 2.2 3.0 84 90 101 112 135 157
BA1404 3.0 5.0 102 109 123 137 166 174
BA1405 4.0 5.0 123 134 157 179 196 197
BA1406 5.5 7.5 146 160 187 198 196 197
BA2401 7.5 10 186 202 234 266 283 282
BA2402 11 15 248 269 291 286 283 281
BA2403 15 20 313 320 315 316
BA3401 18.5 25 384 420 490 489 471 462
BA3402 22 30 461 503 541 521 500 491
BA3403 30 40 583 563 535 517 498
BA4401 37 50 714 781 914 956
BA4402 45 60 882 961 995 970
BA4403 55 75 1070 1158 1217 1144
BA5401 75 100 1471 1618 1640 1560
BA5402 90 125 1830 1881 1781 1717
BA6401 110 150 2058 2259 2153
BA6402 132 200 2477 2455 2255
BA3501 3.0 3.0 127 141 168 196
BA3502 4.0 5.0 135 150 180 209
BA3503 5.5 7.5 163 181 218 254
BA3504 7.5 10 197 219 263 306
BA3505 11 15 267 296 354 412
BA3506 15 20 362 399 475 471
BA3507 18.5 25 448 486 477 471
BA4601 18.5 25 409 470 590 711
BA4602 22 30 496 568 712 857
BA4603 30 40 660 754 941 1063
BA4604 37 50 798 908 1083 1058
BA4605 45 60 985 1115 1080 1058
BA4606 55 75 1060 1179 1130 1105
BA5601 75 100 1818 2129 2258 2203
BA5602 90 125 2176 2320 2215 2189
BA6601 110 150 2573 2512 2438
BA6602 132 175 3106 2512 2438
