170 Affinity User Guide
www.controltechniques.com Issue Number: 5
Parameter
Range(
Ú) Default(Ö)
Type
OL RFC OL RFC
8.01 T24 digital I/O 1 state
OFF (0) or On (1)
RO Bit NC PT
8.02 T25 digital I/O 2 state RO Bit NC PT
8.03 T26 digital I/O 3 state RO Bit NC PT
8.04 T27 digital input 4 state RO Bit NC PT
8.05 T28 digital input 5 state RO Bit NC PT
8.06 T29 digital input 6 state RO Bit NC PT
8.07 Relay state RO Bit NC PT
8.08 T22 24V output state RO Bit NC PT
8.09 Drive enable indicator RO Bit NC PT
8.10 Drive enable mode select
OFF (0)
RW Bit US
8.11 T24 digital I/O 1 invert RW Bit US
8.12 T25 digital I/O 2 invert RW Bit US
8.13 T26 digital I/O 3 invert RW Bit US
8.14 T27 digital input 4 invert RW Bit US
8.15 T28 digital input 5 invert RW Bit US
8.16 T29 digital input 6 invert RW Bit US
8.17 Relay source invert RW Bit US
8.18 T22 24V output source invert On (1) RW Bit US
8.20 Digital I/O read word 0 to 511
RO Uni NC PT
8.21
T24 digital I/O 1 source/
destination
Pr 0.00 to Pr 50.99
Pr 10.02 RW Uni DE PT US
8.22
T25 digital I/O 2 source/
destination
Pr 10.33 RW Uni DE PT US
8.23
T26 digital I/O 3 source/
destination
Pr 6.30 RW Uni DE PT US
8.24 T27 digital input 4 destination Pr 1.54 RW Uni DE PT US
8.25 T28 digital input 5 destination Pr 1.41 RW Uni DE PT US
8.26 T29 digital input 6 destination Pr 0.00 RW Uni DE PT US
8.27 Relay source Pr 10.01 RW Uni PT US
8.28 T22 24V output source Pr 0.00 RW Uni PT US
8.29 Positive logic select {0.51}
OFF (0) or On (1)
On (1) RW Bit PT US
8.30 Open collector output OFF (0) RW Bit US
8.31 T24 digital I/O 1 output select On (1) RW Bit US
8.32 T25 digital I/O 2 output select OFF (0) RW Bit US
8.33 T26 digital I/O 3 output select OFF (0) RW Bit US
8.39
T28 & T29 digital input auto-
selection disable
OFF (0) or On (1) On (1) RW Bit US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
