24 Affinity User Guide
www.controltechniques.com Issue Number: 5
To remove a terminal cover, undo the screw and lift the terminal cover off as shown. The control terminal cover must be removed first before the DC
(size 1) / low voltage DC (sizes 2 and 3) terminal cover can be removed.
When replacing the terminal covers the screws should be tightened with a maximum torque of 1 N m (0.7 lb ft).
Figure 3-4 Removing the standard drive size 1 terminal covers
Figure 3-5 Removing the standard drive size 2 terminal covers
Figure 3-6 Removing the standard drive size 3 terminal covers
