12.2.2 Overall EMC filter dimensions
Optional external EMC filter dimensions
CT part
number
Manufacturer
Dimension Weight
HWDkglb
4200-6125
Schaffner
440 mm (17.323 in) 100 mm (3.937 in) 45 mm (1.772in) 2.25 5.0
4200-6124
4200-6218 428.5 mm (16.870 in) 155 mm (6.102 in) 55 mm (2.165 in) 4.5 9.9
4200-6318
414 mm (16.299 in) 250 mm (9.842 in) 60 mm (2.362 in) 8.75 19.34200-6319
4200-6320
4200-6118
440 mm (17.323 in) 100 mm (3.937 in) 45 mm (1.772in) 1.4 3.1
4200-6119
4200-6210 428.5 mm (16.870 in) 155 mm (6.102 in) 55 mm (2.165 in) 2 4.4
4200-6305
414 mm (16.299 in) 250 mm (9.842 in) 60 mm (2.362 in) 3.5 7.74200-6307
4200-6309
4200-6406
300 mm (11.811 in)
225 mm (8.858 in)
100 mm (3.937 in)
48.8
4200-6408 208 mm (8.189 in) 3.8 8.4
4200-6503 249 mm (9.803 in) 120 mm (4.724 in) 6.8 15
4200-6504 225 mm (8.858 in) 100 mm (3.937 in) 4.4 9.7
4200-6603 295 mm (11.614 in)
230 mm (9.055 in) 136 mm (5.354 in) 5.25 11.6
4200-6604 357 mm (14.055 in)
4200-6125
440 mm (17.323 in) 100 mm (3.937 in) 45 mm (1.772in) 2.25 5.0
4200-6124
4200-6218 428.5 mm (16.870 in) 155 mm (6.102 in) 55 mm (2.165 in) 4.5 9.9
4200-6318
414 mm (16.299 in) 250 mm (9.842 in) 60 mm (2.362 in) 8.75 19.34200-6319
4200-6320
4200-6121
Epcos
450 mm (17.717 in) 100 mm (3.937 in) 45 mm (1.772 in) 2.1 4.6
4200-6120
4200-6211 431.5 mm (16.988 in) 155 mm (6.102 in) 55 mm (2.165 in) 3.3 7.3
4200-6306
425 mm (16.732 in) 250 mm (9.843 in) 60 mm (2.362 in) 5.1 11.2
4200-6308
4200-6405
300 mm (11.811 in)
207 mm (8.150 in)
90 mm (3.543 in)
7.8 17.2
4200-6407 205 mm (8.071 in) 8.0 17.6
4200-6501
249 mm (9.803 in) 120 mm (4.724 in)
12.0 26.5
4200-6502 10.0 22.0
4200-6601
364 mm (14.331 in) 230 mm (9.055 in) 147 mm (5.787 in) 8.6 19.0
4200-6602
