C.rtg SMARTCARD trip: The voltage and/or current rating of the source and destination drives are different

186

Drive rating dependent parameters (parameters with the RA coding) are likely to have different values and ranges with drives of

different voltage and current ratings. Parameters with this attribute will not be transferred to the destination drive by SMARTCARDs

when the rating of the destination drive is different from the source drive and the file is a parameter file. Drive rating dependent

parameters will be transferred if only the current rating is different and the file is a differences from default type file.

Press the red reset button

Drive rating parameters are:

The above parameters will be set to their default values.

C.TyP SMARTCARD trip: SMARTCARD parameter set not compatible with drive

187

Press the reset button

Ensure destination drive type is the same as the source parameter file drive type

dESt Two or more parameters are writing to the same destination parameter

199 Set Pr xx.00 = 12001 check all visible parameters in the menus for duplication

EEF

EEPROM data corrupted - Drive mode becomes open loop and serial comms will timeout with remote keypad on the drive

RS485 comms port.

31 This trip can only be cleared by loading default parameters and saving parameters

Et External trip from input on terminal 31

Check terminal 31 signal

Check value of Pr 10.32

Enter 12001 in Pr xx.00 and check for parameter controlling Pr 10.32

Ensure Pr 10.32 or Pr 10.38 (=6) are not being controlled by serial comms

HF01 Data processing error: CPU address error
