Figure 3-23 Surface mounting the standard size 5 drive with conduit connection boxes installed
310.0mm (12.202in)
296.0mm (11.671in)
1150.0mm
(45.270in)
258.6
±
±
1.0mm
(10.181 0.039in)
1122.0mm
(44.175in)
839.3
±
±
1.0mm
(33.043 0.039in)
973.3 1.0mm
(38.319 0.039in)
±
±
134.0 1.0mm
(5.276 0.039in)
±
±
9.20
±
±
1.0mm
(0.362 0.039in)
277.0
±
±
1.0mm
(10.906 0.039in)
