EZMotion User/Programming Guide iii
Revision A8 www.controltechniques.com
Document Conventions
Manual conventions have been established to help you learn to use this manual quickly and easily. As much as possible, these conventions correspond
to those found in other Microsoft® Windows® compatible software documentation.
Menu names and commands are printed in bold type: the File menu.
Dialog box names begin with uppercase letters and are printed in bold type: the Axis Limits dialog box.
Dialog box field names are in quotes: “Field Name”.
Button names are bold-italic: OK button.
Source code is printed in Courier font:
Case ERMS.
In addition, you will find the following typographic conventions throughout this manual.
NOTE
For the purpose of this manual and product, “Note” indicates essential information about the product or the respective part of the manual.
Throughout this manual, the word “drive” refers to either the Unidrive SP or the Digitax ST. Throughout this manual, the word “EZMotion” refers to the
SM-EZMotion module in either the Unidrive SP or the Digitax ST Base drive and the Digitax STEZMotion drive.
Safety Instructions
General Warning
Failure to follow safe installation guidelines can cause death or serious injury. The voltages used in the product can cause severe electric shock and/or
burns and could be lethal. Extreme care is necessary at all times when working with or adjacent to the product. The installation must comply with all
relevant safety legislation in the country of use.
Qualified Person
For the purpose of this manual and product, a “qualified person” is one who is familiar with the installation, construction and operation of the equipment
and the hazards involved. In addition, this individual has the following qualifications:
• Is trained and authorized to energize, de-energize, clear and ground and tag circuits and equipment in accordance with established safety
practices.
• Is trained in the proper care and use of protective equipment in accordance with established safety practices.
• Is trained in rendering first aid.
This Represents
bold
Characters that you must type exactly as they appear. For example, if you are directed to type
a:setup, you should type all the bold characters exactly as they are printed.
italic
Placeholders for information you must provide. For example, if you are directed to type
filename, you should type the actual name for a file instead of the word shown in italic type.
ALL CAPITALS Directory names, file names, key names, and acronyms.
SMALL CAPS Non-printable ASCII control characters.
KEY1+KEY2
example: (Alt+F)
A plus sign (+) between key names means to press and hold down the first key while you press
the second key.
KEY1,KEY2
example: (Alt,F)
A comma (,) between key names means to press and release the keys one after the other.
“Warning” indicates a potentially hazardous situation that, if not avoided, could result in death or serious injury.
“Caution” indicates a potentially hazardous situation that, if not avoided, may result in minor or moderate injury.
WARNING
CAUTION
