PACSystems VersaMax Genius Network Interface User Manual Section 1
GFK-1535D Jan 2023
Introduction 9
Available I/O Modules
The following types of VersaMax I/O Modules are available:
Discrete Input Modules
Module
Part Number
Input 120VAC 8 Point Grouped Module
IC200MDL140
Input 240VAC 8 Point Grouped Module
IC200MDL141
Input 120VAC 8 Point Isolated Module
IC200MDL143
Input 240VAC 4 Point Isolated Module
IC200MDL144
Input 120VAC (2 Groups of 8) 16-Point Module
IC200MDL240
Input 240VAC (2 Groups of 8) 16-Point Module
IC200MDL241
Input 120VAC 16 Point Isolated Module
IC200MDL243
Input 240VAC 8 Point Isolated Module
IC200MDL244
Input 125VDC Positive/Negative Logic Grouped 8-Point Module
IC200MDL631
Input 125VDC Positive/Negative Logic Grouped 16-Point Module
IC200MDL632
Input 48VDC Positive/Negative Logic Grouped 16-Point Module
IC200MDL635
Input 48VDC Positive/Negative Logic Grouped 32-Point Module
IC200MDL636
Input 24VDC Positive/Negative Logic (2 Groups of 8) 16 Point Module
IC200MDL640
Input 5/12VDC (TTL) Positive/Negative Logic 16 Point Module
IC200MDL643
Input 5/12VDC (TTL) Positive/Negative Logic Grouped 32-Point Module
IC200MDL644
Input 24VDC Positive/Negative Logic (4 Groups of 8) 32 Point Module
IC200MDL650
Discrete Output Modules
Output 120VAC 0.5A per Point Isolated 8 Point Module
IC200MDL329
Output 120VAC 0.5A per Point Isolated 16 Point Module
IC200MDL330
Output 120VAC 2.0A per Point Isolated 8 Point Module
IC200MDL331
Output 24VDC Positive Logic 2.0A per Point (1 Group of 8) w/ESCP 8 Point
Module,
IC200MDL730
Output 12/24VDC Positive Logic 0.5A per Point (1 Group of 16) 16 Point
Module
IC200MDL740
Output 24VDC Positive Logic 0.5A per Point (1 Group of 16) w/ESCP 16
Point Module
IC200MDL741
Output 24VDC Positive Logic 0.5A per Point (2 Groups of 16) w/ESCP 32
Point Module
IC200MDL742
Output 5/12/24VDC Negative Logic 0.5A per Point (1 Group of 16) 16 Point
Module
IC200MDL743
Output 5/12/24VDC Negative Logic 0.5A per Point (2 Groups of 16) 32
Point Module
IC200MDL744
Output 12/24VDC Positive Logic 0.5A per Point (2 Groups of 16) 32 Point
Module
IC200MDL750
Output Relay 2.0A per Point Isolated Form A 8 Point Module
IC200MDL930
Output Relay 2.0A per Point Isolated Form A 16 Point Module
IC200MDL940
Discrete Mixed I/O Modules
Mixed 24VDC Positive Logic Input Grouped 20 Point/Output Relay 2.0A per
Point Grouped 12 Point Module
IC200MDD840
Mixed 24VDC Positive Logic Input 20 Point/Output 12 Point / (4) High-
Speed Counter, PWM, or Pulse Train Configurable Points
IC200MDD841
Mixed 16 Point Grouped Input 24VDC Pos/Neg Logic/16 Pt Grouped
Output 24VDC Pos. Logic 0.5A w/ESCP
IC200MDD842
Mixed 24VDC Positive Logic Input Grouped 10 Point / Output Relay 2.0A
per Point 6 Point Module
IC200MDD843
Mixed 24 VDC Pos/Neg Logic Input Grouped 16 Point / Output 12/24VDC
Pos. Logic 0.5A 16-Point Module
IC200MDD844
