PACSystems VersaMax Genius Network Interface User Manual Section 1
GFK-1535D Jan 2023
Introduction 10
Discrete Mixed I/O Modules
Module
Part Number
Mixed 16 Point Grouped Input 24VDC Pos/Neg Logic/8 Pt Relay Output
2.0A per Pt Isolated Form A
IC200MDD845
Mixed 120VAC Input 8 Point/Output Relay 2.0A per Point 8 Point Module
IC200MDD846
Mixed 240VAC Input 8 Point/Output Relay 2.0A per Point 8 Point Module
IC200MDD847
Mixed 120VAC Input 8 Point/Output 120VAC 0.5A per Point Isolated 8
Point Module
IC200MDD848
Mixed 120VAC In Isolated 8 Point/Output Relay 2.0A Isolated 8 Point
Module
IC200MDD849
Mixed 240VAC In Isolated 4 Point/Output Relay 2.0A Isolated 8 Point
Module
IC200MDD850
Mixed, Output 12/24VDC Pos. Grouped 16 Pts/Input 5/12VDC Pos/Neg
Grp16 Pts
IC200MDD851
Analog Input Modules
Analog Input Module, 12 Bit Voltage/Current 4 Channels
IC200ALG230
Analog Input Module, 16 Bit Voltage/Current, 1500VAC Isolation, 8
Channels
IC200ALG240
Analog Input Module, 12 Bit Voltage/Current 8 Channels
IC200ALG260
Analog Input Module, 15-Bit Voltage Differential 8 Channels
IC200ALG261
Analog Input Module, 15-Bit Current Differential 8 Channels
IC200ALG262
Analog Input Module, 15 Bit Voltage 15 Channels
IC200ALG263
Analog Input Module, 15 Bit Current 15 Channels
IC200ALG264
Analog Input Module, 15 Bit Voltage 15 Channels, Enhanced Overvoltage
Protection
IC200ALG265
Analog Input Module, 15 Bit Current 15 Channels, Enhanced Overvoltage
Protection
IC200ALG266
Analog Input Module, 16 Bit RTD, 4 Channels
IC200ALG620
Analog Input Module, 16 Bit Thermocouple, 7 Channels
IC200ALG630
Analog Output Modules
Analog Output Module, 12 Bit Current, 4 Channels
IC200ALG320
Analog Output Module, 12 Bit Voltage 4 Channels. 0 to +10VDC Range
IC200ALG321
Analog Output Module, 12 Bit Voltage 4 Channels. -10 to +10VDC Range
IC200ALG322
Analog Output Module, 13-Bit Voltage 8 Channels
IC200ALG325
Analog Output Module, 13-Bit Current 8 Channels
IC200ALG326
Analog Output Module, 13-Bit Voltage 12 Channels
IC200ALG327
Analog Output Module, 13 Bit Current 12 Channels
IC200ALG328
Analog Output Module, 13-Bit Voltage 8 Channels
IC200ALG325
Analog Output Module, 16 Bit Voltage/Current, 1500VAC Isolation, 4
Channels
IC200ALG331
Analog Mixed I/O Modules
Analog Mixed Module, Input Current 4 Channels, Output Current 2
Channels
IC200ALG430
Analog Mixed Module, 0 to +10VDC Input 4 Channels, Output 0 to +10VDC
2 Channels
IC200ALG431
Analog Mixed Module, 12 Bit -10 to +10VDC, Input 4 Channels/Output -10
to +10VDC 2 Channels
IC200ALG432
