Emerson Site Supervisor User Manual

Appendix B: Troubleshooting • B-3
Problems with Temp Sensor or
Pressure Transducer Displaying
Proper Value
16AI input dip switches are set
improperly.
The 16 dip switches on the 16AI board corre-
spond to each of the inputs:
Dip Switches Up = Temperature Sensor
Dip Switches Down = Pressure Transducer
Incorrect board and point
address.
Set proper board and point settings for both
input and output: Go to the Inputs tab in the
application’s Setup screen and check Board
and Point.
Incorrect sensor type. Verify that the sensor type in Site Supervisor is
the same as the sensor installed. (For example,
“5V-200PSI” is a 5-volt powered 200PSI pres-
sure transducer, and “Temperature” is the stan-
dard Emerson Retail Solutions temperature
sensor.
NOTE: The previous Eclipse and Standard
sensors are now 5V and 12V respectively.
For 16AI boards:
1. Log into Site Supervisor.
2. Click the Site Map icon.
3. Under Control Status, select
System.
4. Click Details.
5. Under 16AI Board DETAILS, select
AI01.
6. Check the value of the Sensor Type.
7. Click Edit to change.
For Onboard I/O:
1. Log into Site Supervisor.
2. Click the Site Map icon.
3. Under Control Status, select
System.
4. Click Onboard IO along the bottom
of the screen.
5. Click Details.
6. Under Onboard IO DETAILS, click
Setup.
7. Check the desired sensor type value
from the list and click Edit to make
changes.
SYMPTOM POSSIBLE PROBLEM SOLUTION
