Description of parameters (ToF Tool) Cerabar S/Deltabar S
106 Endress+Hauser
CUST. UNIT FACT. H
Entry
Enter conversion factor for a customer-specific level unit.
The conversion factor must be entered in relation to the SI unit "m".
→ See also CUSTOMER UNIT H.
Prerequisite:
• LIN. MEASURAND = level, HEIGHT UNIT = user unit
Example:
– You want the measured value to be displayed in "PU" (PU: packing unit).
– MEASURED VALUE = 0.5 m i 1 PU
– Entry CUSTOMER UNIT H: PU
– Entry CUST. UNIT FACT. H: 2
– Result: MEASURED VALUE = 1 PU
Factory setting:
1.0
UNIT VOLUME
Selection
Select volume unit.
Prerequisite:
• LIN. MEASURAND = volume
Options:
•l
•hl
•cm
3
•dm
3
•m
3
•m
3
E
3
•ft
•ft
3
E
3
•gal
•Igal
•bbl
•User unit, → see also the following parameter description for CUSTOMER UNIT V and
CUST. UNIT FACT. V.
Factory setting:
m
3
CUSTOMER UNIT V
Entry
Enter text (unit) for customer-specific volume unit.
You can enter a maximum of eight alphanumeric characters here.
→ See also CUST. UNIT FACT. V
Prerequisite:
• LIN. MEASURAND = volume, UNIT VOLUME = user unit
!
Note!
Only the first five characters are shown on the on-site display. For example, if "crates" is
specified as the customer-specific unit, "crate" is displayed.
If the unit contains a slash, up to eight characters can be shown on the on-site display.
The maximum number of characters in the counter is again limited to five. For example,
if "crates/m2" is specified as the customer-specific unit, "crate/m2" is displayed. In the
ToF Tool, all eight characters are displayed.
Factory setting:
_ _ _ _ _ _ _ _
CUST. UNIT FACT. V
Entry
Enter conversion factor for a customer-specific volume unit.
The conversion factor must be entered in relation to the SI unit "m
3
".
→ See also CUSTOMER UNIT V.
Prerequisite:
• LIN. MEASURAND = volume, UNIT VOLUME = user unit
Example:
– You want the measured value to be displayed in "buckets".
– MEASURED VALUE = 0.01 m3 i 1 bucket
– Entry CUSTOMER UNIT V: bucket
– Entry CUST. UNIT FACT. V: 100
– Result: MEASURED VALUE = 1 bucket
Factory setting:
1.0
ToF Tool, Table 7: OPERATING MENU → SETTINGS → BASIC SETUP "Level", LEVEL MODE "Linear"
Parameter name Description
