Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 105
ToF Tool, Table 7: OPERATING MENU → SETTINGS → BASIC SETUP "Level", LEVEL MODE "Linear"
Parameter name Description
The following parameters are displayed if you selected the "Linear" option for the LEVEL MODE parameter. For this level
type, the measured variable (level, volume, mass or %) is in direct proportion to the measured pressure.
Prerequisite:
• MEASURING MODE = level.
• LEVEL MODE = linear (→ see also Page 103).
Note:
See also
– Page 101 ff, ToF Tool, table 6 BASIC SETUP – general
– Page 129 ff, ToF Tool, table 12: EXTENDED SETUP
– Page 143 ff, ToF Tool, table 22: PROCESS VALUES
– Page 75 ff, ToF Tool, Section 8 "Level measurement (ToF Tool)".
LIN. MEASURAND
Selection
Select measured variable.
Options:
• Level
•Volume
•Mass
• % (level)
Factory setting:
% (level)
HEIGHT UNIT
Selection
Select level unit.
Prerequisite:
• LIN. MEASURAND = level
Options:
•mm
•cm
•dm
•m
•inch
•ft
•User unit, → see also the following parameter description for CUSTOMER UNIT H
and CUST. UNIT FACT. H.
Factory setting:
m
CUSTOMER UNIT H
Entry
Enter text (unit) for customer-specific level unit.
You can enter a maximum of eight alphanumeric characters here.
→ See also CUST. UNIT FACT. H.
Prerequisite:
• LIN. MEASURAND = level, HEIGHT UNIT = user unit
!
Note!
Only the first five characters are shown on the on-site display. For example, if "crates" is
specified as the customer-specific unit, "crate" is displayed.
If the unit contains a slash, up to eight characters can be shown on the on-site display.
The maximum number of characters in the counter is again limited to five. For example,
if "crates/m2" is specified as the customer-specific unit, "crate/m2" is displayed. In the
ToF Tool, all eight characters are displayed.
Factory setting:
_ _ _ _ _ _ _ _
