Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 103
LEVEL MODE
Selection
Select level type.
Options:
• Linear: the measured variable (level, volume, mass or %) is in direct proportion to the
measured pressure. → See also Page 105 ff, ToF Tool, table 7.
• Pressure linearized: the measured variable (volume, mass or %) is not in direct
proportion to the measured pressure such as in the case of containers with a conical
outlet. For the calibration, enter a linearisation table with at least 2 and not more than
32 points. → See also Page 112 ff, ToF Tool, table 8.
• Height linearized: select this level type if you require two measured variables or if the
container shape is given with value pairs, e.g. height and volume.
The following combinations are possible:
–Height + volume
–Height + mass
–Height + %
– %-height + volume
– %-height + mass
– %-height + %
Perform two calibrations for this level type. First for the measured variable height or %-
height like for the "Linear" option and then for the measured variable volume, mass or
% like for the "Pressure linearized" option. → See also Page 117 ff, ToF Tool, table 9.
Factory setting:
Linear
→ For LEVEL MODE = linear, see Page 105, ToF Tool, table 7.
→ For LEVEL MODE = pressure linearized, see Page 112, ToF Tool, table 8.
→ For LEVEL MODE = height linearized, see Page 117, ToF Tool, table 9.
ToF Tool, Table 6 : OPERATING MENU → SETTINGS → BASIC SETUP "Level"
Parameter name Description
