Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 117
ToF Tool, Table 9: OPERATING MENU → SETTINGS → BASIC SETUP "Level",
LEVEL MODE "Height linearized"
Parameter name Description
The following parameters are displayed if you selected the "Height linearized" option for the LEVEL MODE parameter.
Select this level type if you require two measured variables or if the container shape is given with value pairs, e.g. height
and volume.
The following combinations are possible:
• Height + volume
• Height + mass
• Height + %
•%-height + volume
•%-height + mass
•%-height + %
The 1st measured variable (%-height or height) must be in direct proportion to the measured pressure. The 2nd measured
variable (volume, mass or %) must not be in direct proportion. A linearisation table must be entered for the 2nd measured
variable. The 2nd measured variable is assigned to the 1st measured variable by means of this table.
Prerequisite:
•MEASURING MODE = level
• LEVEL MODE = height linearized (→ see also Page 103).
Note:
See also
– Page 101 ff, ToF Tool, table 6: BASIC SETUP – general
– Page 129 ff, ToF Tool, table 12: EXTENDED SETUP
– Page 132 ff, ToF Tool, table 14: LINEARISATION – on-site operation
– Page 143 ff, ToF Tool, table 22: PROCESS VALUES
– Page 75 ff, Section 8 "Level measurement (ToF Tool)".
COMB. MEASURAND
Selection
Select measured variable.
Options:
• Height and volume
• Height and mass
• Height and %
• %-height and volume
• %-height and mass
• %-height and %
Factory setting:
%-height and %
HEIGHT UNIT
Selection
Select level unit for the 1st measured variable.
Prerequisite:
• COMB. MEASURAND = height and volume, height and mass or height and %
Options:
•mm
•dm
•cm
•m
•inch
•ft
•User unit, → see also the following parameter description for CUSTOMER UNIT H
and CUST. UNIT FACT. H.
Factory setting:
m
