Description of parameters (ToF Tool) Cerabar S/Deltabar S
118 Endress+Hauser
CUSTOMER UNIT H
Entry
Enter text (unit) for customer-specific level unit.
You can enter a maximum of eight alphanumeric characters here. → See also CUST.
UNIT FACT. H.
Prerequisite:
• COMB. MEASURAND = height and volume, HEIGHT UNIT = user unit
• COMB. MEASURAND = height and mass, HEIGHT UNIT = user unit
• COMB. MEASURAND = height and %, HEIGHT UNIT = user unit
!
Note!
Only the first five characters are shown on the on-site display. For example, if "crates" is
specified as the customer-specific unit, "crate" is displayed.
If the unit contains a slash, up to eight characters can be shown on the on-site display.
The maximum number of characters in the counter is again limited to five. For example,
if "crates/m2" is specified as the customer-specific unit, "crate/m2" is displayed. In the
ToF Tool, all eight characters are displayed.
Factory setting:
_ _ _ _ _ _ _ _
CUST. UNIT FACT. H
Entry
Enter conversion factor for a customer-specific level unit.
The conversion factor must be entered in relation to the SI unit "m". → See also
CUSTOMER UNIT H.
Prerequisite:
• COMB. MEASURAND = height and volume, HEIGHT UNIT = user unit
• COMB. MEASURAND = height and mass, HEIGHT UNIT = user unit
• COMB. MEASURAND = height and %, HEIGHT UNIT = user unit
Example:
– You want the measured value to be displayed in "PU" (PU: packing unit).
– MEASURED VALUE = 0.5 m i 1 PU
– Entry CUSTOMER UNIT H: PU
– Entry CUST. UNIT FACT. H: 2
– Result: MEASURED VALUE = 1 PU
Factory setting:
1.0
UNIT VOLUME
Selection
Select the volume unit for the 2nd measured value.
Prerequisite:
• COMB. MEASURAND = height and volume or %-height and volume
Options:
•l
•hl
•cm
3
•dm
3
•m
3
•m
3
E
3
•ft
•ft
3
E
3
•gal
•Igal
•bbl
•User unit, → see also the following parameter description for CUSTOMER UNIT V and
CUST. UNIT FACT. V.
Factory setting:
m
3
ToF Tool, Table 9: OPERATING MENU → SETTINGS → BASIC SETUP "Level",
LEVEL MODE "Height linearized"
Parameter name Description
