Cerabar S/Deltabar S Description of parameters (ToF Tool)
Endress+Hauser 123
CUSTOMER UNIT H
Entry
Enter text (unit) for customer-specific level unit.
You can enter a maximum of eight alphanumeric characters here.
→ See also CUST. UNIT FACT. H.
Prerequisite:
• COMB. MEASURAND = %-height and volume, CALIBRATION MODE = dry,
HEIGHT UNIT = user unit
• COMB. MEASURAND = %-height and mass, CALIBRATION MODE = dry,
HEIGHT UNIT = user unit
• COMB. MEASURAND = %-height and %, CALIBRATION MODE = dry,
HEIGHT UNIT = user unit
!
Note!
Only the first five characters are shown on the on-site display. For example, if "crates" is
specified as the customer-specific unit, "crate" is displayed.
If the unit contains a slash, up to eight characters can be shown on the on-site display.
The maximum number of characters in the counter is again limited to five. For example,
if "crates/m2" is specified as the customer-specific unit, "crate/m2" is displayed. In the
ToF Tool, all eight characters are displayed.
Factory setting:
_ _ _ _ _ _ _ _
CUST. UNIT FACT. H
Entry
Enter conversion factor for a customer-specific level unit.
The conversion factor must be entered in relation to the SI unit "m". → See also
CUSTOMER UNIT H.
Prerequisite:
• COMB. MEASURAND = %-height and volume, CALIBRATION MODE = dry,
HEIGHT UNIT = user unit
• COMB. MEASURAND = %-height and mass, CALIBRATION MODE = dry,
HEIGHT UNIT = user unit
• COMB. MEASURAND = %-height and %, CALIBRATION MODE = dry,
HEIGHT UNIT = user unit
Example:
– You want the measured value to be displayed in "PU" (PU: packing unit).
– MEASURED VALUE = 0.5 m i 1 PU
– Entry CUSTOMER UNIT H: PU
– Entry CUST. UNIT FACT. H: 2
– Result: MEASURED VALUE = 1 PU
Factory setting:
1.0
100% POINT
Entry
Enter level value for 100% point.
Prerequisite:
• COMB. MEASURAND = %-height and volume, CALIBRATION MODE = dry
• COMB. MEASURAND = %-height and mass, CALIBRATION MODE = dry
• COMB. MEASURAND = %-height + %, CALIBRATION MODE = dry
Example:
– The 100 %-point should correspond to 4 m.
– Select the "m" unit via the HEIGHT UNIT parameter.
– Enter the value "4" for this parameter (100% POINT).
Factory setting:
1.0
ToF Tool, Table 9: OPERATING MENU → SETTINGS → BASIC SETUP "Level",
LEVEL MODE "Height linearized"
Parameter name Description
