Cerabar S/Deltabar S Description of parameters (FF configuration program)
Endress+Hauser 27
ST_REV
Display
Index: 1
Data type: Unsigned16
Access: Read only
Displays the counter for static parameters of the Resource Block
This counter is incremented by one with each change of a static parameter of the Resource
Block. The counter counts up to 65535 and then starts again at zero.
STRATEGY
Entry
Index: 3
Data type: Unsigned16
Access: Auto, OOS
Enter a user-specific value for grouping and thus faster evaluation of the blocks.
Grouping takes place by entering the same numerical value for the STRATEGY parameter of
the block in question. This value is neither checked nor processed by the Resource Block.
Input range:
0...65535
Factory setting:
0
TAG_DESC
Entry
Index: 2
Data type: Octet String
Access: Auto, OOS
Enter a description for the associated block or the measuring point e.g. TAG number (max.
32 alphanumeric characters).
TEST_RW/
TEST READ WRITE
Display
Index: 8
Data type: DS-85
Access: Auto, OOS
This parameter is only needed for the FF conformance test and does not have any relevance
during measuring operation.
UPDATE_EVT
Display
Index: 35
Data type: DS-73
Access: Read only
The UPDATE_EVT parameter is a structured parameter consisting of five elements.
UNACKNOWLEDGED
• This element is set to "Unacknowledged" as soon as a static parameter changes.
UPDATE_STATE
• Displays whether the change was reported.
TIME_STAMP
• Displays the date and time a static parameter was changed.
STATIC_REVISION
• The revision counter is increased when a static parameter changes.
RELATIVE_INDEX
• Displays the altered parameter in the form of the relative index. See also this table,
"Parameter, Index" column.
WRITE_ALM
Display
Index: 40
Data type: DS-72
Access: Read only
The WRITE_ALM parameter is a structured parameter consisting of five elements.
UNACKNOWLEDGED
• If the "Deactivated" option was selected for the alarm occurring via the ACK_OPTION
parameter, this alarm can only be acknowledged via this element.
ALARM_STATE
• Status display of the write protection alarm.
TIME_STATE
• Displays the time the alarm occurred.
SUB_CODE
• Displays the reason why the alarm was reported.
VALUE
• Displays the value of the parameter at the time the alarm was reported.
Resource Block
Parameter Description
