Description of parameters (FF configuration program) Cerabar S/Deltabar S
46 Endress+Hauser
LEVEL_100_PERCENT_
VALUE/
100% POINT
Entry
Index: 64
Data type: Float
Access: Auto, OOS
Enter level value for 100% point.
Prerequisite:
• MEASURAND_COMBINED = %-height and volume, LEVEL_ADJUST_MODE = dry
• MEASURAND_COMBINED = %-height and mass, LEVEL_ADJUST_MODE = dry
• MEASURAND_COMBINED = %-height + %, LEVEL_ADJUST_MODE = dry
– MEASURAND_COMBINED = COMB. MEASURAND
– LEVEL_ADJUST_MODE = CALIBRATION MODE
Example:
– The 100 %-point should correspond to 4 m.
– Select the "m" unit via the HEIGHT_UNIT/ HEIGHT UNIT parameter.
– Enter the value "4" for this LEVEL_100_PERCENT_VALUE/100% POINT parameter.
Factory setting:
1.0
LINEAR_LEVEL_MIN/
LEVEL MIN.
Entry
Index: 65
Data type: Float
Access: Auto, OOS
Enter the minimum level to be expected.
The input limits for the calibration (editing limits) are derived from the value entered. The
closer the value entered corresponds to the minimum level to be expected, the more accurate
the measurement result.
Factory setting:
0.0
LINEAR_LEVEL_MAX/
LEVEL MAX.
Entry
Index: 66
Data type: Float
Access: Auto, OOS
Enter the maximum level to be expected.
The input limits for the calibration (editing limits) are derived from the value entered. The
closer the value entered corresponds to the maximum level to be expected, the more
accurate the measurement result.
Factory setting:
100.0
LEVEL_MEASUREMENT
_DENSITY/
PROCESS DENSITY
Entry
Index: 67
Data type: Float
Access: Auto, OOS
Enter a new density value for density correction.
The calibration was carried out with the medium water, for example. Now the container is to
be used for another fluid with another density. The calibration is corrected appropriately by
entering the new density value in the LEVEL_MEASUREMENT_DENSITY/ PROCESS
DENSITY parameter.
Factory setting:
1.0
FLOW_TYPE/
FLOW-MEAS. TYPE
Selection
Index: 68
Data type: Unsigned8
Access: Auto, OOS
Select the flow type.
Prerequisite:
• Deltabar S differential pressure transmitter
Options:
• Volume p. cond. (volume under operating conditions)
• Gas norm. cond. (norm volume under norm conditions in Europe: 1013.25 mbar and
273.15 K (0 °C))
• Gas std. cond. (standard volume under standard conditions in USA: 1013.25 mbar
(14.7 psi) and 288.15 K (15 °C/59 °F))
• Mass p. cond. (mass under operating conditions)
Factory setting:
Volume p. cond.
Pressure Transducer Block
Parameter Description
