Description of parameters (FF configuration program) Cerabar S/Deltabar S
54 Endress+Hauser
COUNTER_PMAX/
COUNTER: P > Pmax
Display
Index: 23
Data type: DS-65
Access: Read only
The COUNTER P_PMAX parameter is a structured parameter consisting of two elements.
VALUE
• Displays the overpressure counter of the sensor
The limit value is: upper nominal pressure limit of sensor + 10 % of upper nominal
pressure limit of sensor. You can reset this counter by means of the
RESET_TRANSMITTER_OBSERVATION/ RESET PEAKHOLD parameter.
STATUS
• Displays the status.
!
Note!
• You can transfer the value and status of the COUNTER_PMAX parameter via the
CHANNEL parameter (→ Page 67) in the Analog Input Block. For this purpose, the
CHANNEL must be set to "5".
• You can transfer the value and status of the COUNTER_PMAX parameter via the
CHANNEL parameter in the Discrete Output Block. For this purpose, the CHANNEL must
be set to "1".
PRESSURE_1_MAX_
RESETABLE/
MAX. MEAS. PRESS.
Display
Index: 23
Data type: DS-65
Access: Read only
The PRESSURE_1_MAX_RESETABLE parameter is a structured parameter consisting of two
elements.
VALUE
• Displays the largest measured pressure value (peak hold indicator). You can reset this
maximum indicator by means of the RESET_TRANSMITTER_OBSERVATION/RESET
PEAKHOLD parameter.
STATUS
• Displays the status.
!
Note!
You can transfer the value and status of the PRESSURE_1_MAX_RESETABLE parameter via
the CHANNEL parameter (→ Page 67) in the Analog Input Block. For this purpose, the
CHANNEL must be set to "4".
COUNTER_PMIN/
COUNTER: P < Pmin
Display
Index: 25
Data type: Unsigned16
Access: Read only
Displays the vacuum pressure counter of the sensor
The limit value is: lower nominal pressure limit of sensor – 10 % of upper nominal pressure
limit of sensor. You can reset this counter by means of the
RESET_TRANSMITTER_OBSERVATION/ RESET PEAKHOLD parameter.
PRESSURE_1_MIN_
RESETABLE/
MIN. PRESSURE
Display
Index: 26
Data type: Float
Access: Read only
Displays the smallest measured pressure value (peak hold indicator). You can reset this
maximum indicator by means of the RESET_TRANSMITTER_OBSERVATION/RESET
PEAKHOLD parameter.
COUNTER_TMAX/
COUNTER: T > Tmax
Display
Index: 27
Data type: Unsigned16
Access: Read only
Displays the number of times the specified temperature range of the sensor has been
overshot. You can reset this counter by means of the RESET_TRANSMITTER_
OBSERVATION/ RESET PEAKHOLD parameter.
TEMPERATURE_1_MAX
_RESETABLE/
MAX. MEAS.TEMP.
Display
Index: 28
Data type: Float
Access: Read only
Displays the largest measured temperature in the sensor (peak hold indicator). You can reset
this maximum indicator by means of the RESET_TRANSMITTER_OBSERVATION/RESET
PEAKHOLD parameter.
Service Transducer Block
Parameter Description
