Description of parameters (FF configuration program) Cerabar S/Deltabar S
72 Endress+Hauser
SIMULATE
Entry, Display
Index: 9
Data type: DS-82
Access: Auto, Man, OOS
The SIMULATE parameter is a structured parameter consisting of five elements.
Since the value and status specified here runs through the entire algorithm, the behaviour of
the Analog Input Block can be checked.
SIMULATE_STATUS
• Enter the status for simulation.
SIMULATE_STATUS
• Enter simulation value.
TRANSDUCER_STATUS
• Displays the current status of the Transducer Block which is linked to the Analog Input
Block by means of the CHANNEL parameter.
TRANSDUCER_VALUE
• Displays the current process value of the Transducer Block which is linked to the Analog
Input Block by means of the CHANNEL parameter.
ENABLE_DISABLE
• Switch simulation mode on and off.
!
Note!
The "Simulation" DIP switch on the electronic insert must be set to "On". → See also
Operating Instructions BA301P (Deltabar S) and BA302P (Cerabar S), Section 5.6
"Simulation".
Factory setting:
Simulation disabled (simulation mode not active)
ST_REV
Display
Index: 1
Data type: Usigned16
Access: Read only
Displays the counter for the static parameters of the Analog Input Block
This counter is increased by one with each change to a static parameter of the Analog Input
Block. The counter counts to 65535 and then starts again at zero.
STATUS_OPTS
Selection
Index: 14
Data type: Bit String
Access: OOS
Specify status treatment and processing of the output parameter OUT.
Factory setting:
No option active
STRATEGY
Entry
Index: 3
Data type: Unsigned16
Access Auto, Man, OOS
Enter a user-specific value for grouping and thus faster evaluation of the blocks.
Grouping takes place by entering the same numeric value for the STRATEGY parameter of
the block in question.
Input range:
0...65535
Factory setting:
0
TAG_DESC
Entry
Index: 2
Data type:
Octet String
Access: Auto, OOS
Enter a description for the associated block or the measuring point e.g. TAG number (max.
32 alphanumeric characters).
UPDATE_EVT
Display
Index: 20
Data type: DS-73
Access: Read only
The UPDATE_EVT parameter is a structured parameter consisting of five elements.
ACKNOWLEDGED
• This element is set to "Unacknowledged" as soon as a static parameter changes.
REPORTED
• Displays the date and time the message was generated.
TIME_STAMP
• Displays the date and time a static parameter was changed.
STATIC_REVISION
• This revision counter is increased with the alarm.
RELATIVE_INDEX
• Displays the altered parameter in the form of the relative index. See also this table,
"Parameter, Index" column.
