Diagnostics and troubleshooting Proline Promass E 300 PROFINET
200 Endress+Hauser
Diagnostic information Remedy instructions
No. Short text
520 I/O 1 to n hardware configuration invalid 1. Check I/O hardware configuration
2. Replace wrong I/O module
3. Plug the module of double pulse output on correct slot
Measured variable status
Quality Good
Quality substatus Ok
Coding (hex) 0x80 to 0x83
Status signal F
Diagnostic behavior Alarm
Influenced measured variables
–
Diagnostic information Remedy instructions
No. Short text
528 Concentration calculation not possible Out of valid range of the selected calculation algorithm
1. Check concentration settings
2. Check measured values, e.g. density or temperature
Measured variable status
Quality Bad
Quality substatus Function check
Coding (hex) 0x3C to 0x3F
Status signal S
Diagnostic behavior Alarm
Influenced measured variables
• Carrier mass flow
• Target corrected volume flow
• Carrier corrected volume flow
• Concentration
• Density
• Mass flow
• Target mass flow
• Carrier volume flow
• Target volume flow
• Volume flow
Diagnostic information Remedy instructions
No. Short text
529 Concentration calculation not accurate Out of valid range of the selected calculation algorithm
1. Check concentration settings
2. Check measured values, e.g. density or temperature
Measured variable status
Quality Bad
Quality substatus Function check
Coding (hex) 0x3C to 0x3F
Status signal S
Diagnostic behavior Warning
Influenced measured variables
• Carrier mass flow
• Target corrected volume flow
• Carrier corrected volume flow
• Concentration
• Density
• Mass flow
• Target mass flow
• Carrier volume flow
• Target volume flow
• Volume flow
