Endress+Hauser Proline Promass E 300 - Configuring the Current Output

Commissioning Proline Promass E 300 PROFINET
98 Endress+Hauser
Navigation
"Setup" menu → Status input
‣
Status input 1 to n
Assign status input
→  98
Terminal number
→  98
Active level
→  98
Terminal number
→  98
Response time status input
→  98
Terminal number
→  98
Parameter overview with brief description
Parameter Description User interface / Selection / User entry
Terminal number Shows the terminal numbers used by the status input module. • Not used
• 24-25 (I/O 2)
• 22-23 (I/O 3)
Assign status input Select function for the status input. • Off
• Reset totalizer 1
• Reset totalizer 2
• Reset totalizer 3
• Reset all totalizers
• Flow override
• Zero point adjustment
Active level Define input signal level at which the assigned function is
triggered.
• High
• Low
Response time status input Define the minimum amount of time the input signal level must
be present before the selected function is triggered.
5 to 200 ms
10.5.8 Configuring the current output
The Current output wizard guides you systematically through all the parameters that have
to be set for configuring the current output.
Navigation
"Setup" menu → Current output
‣
Current output 1 to n
Terminal number
→  99
Signal mode
→  99
Assign current output 1 to n
→  100
