Commissioning Proline Promass E 300 PROFINET
102 Endress+Hauser
10.5.9 Configuring the pulse/frequency/switch output
The Pulse/frequency/switch output wizard guides you systematically through all the
parameters that can be set for configuring the selected output type.
Navigation
"Setup" menu → Advanced setup → Pulse/frequency/switch output
‣
Pulse/frequency/switch output
1 to n
Operating mode
→  102
Parameter overview with brief description
Parameter Description Selection
Operating mode Define the output as a pulse, frequency or switch output. • Pulse
• Frequency
• Switch
Configuring the pulse output
Navigation
"Setup" menu → Pulse/frequency/switch output
‣
Pulse/frequency/switch output
1 to n
Operating mode
→  103
Terminal number
→  103
Signal mode
→  103
Assign pulse output
→  103
Value per pulse
→  103
Pulse width
→  103
Failure mode
→  104
Invert output signal
→  104
