Proline Promass E 300 PROFINET Electrical connection
Endress+Hauser 37
Removing a cable
3 (0.12)
2.
1.
A0029598
 9 Engineering unit mm (in)
1. To remove a cable from the terminal, use a flat-blade screwdriver to push the slot
between the two terminal holes
2. while simultaneously pulling the cable end out of the terminal.
