Enertech Global
EAV - EME/EMD Rev. A Models
Installaon and Operaons Manual
LOAD
HOT WATER
FROM WV
DOMESTIC
HOT WATER
LOAD
WATER
TO WV
DOMESTIC
COLD WATER
DRAIN VALVE
A
B
C
D
F
E
TANK PRESSURE
RELIEF VALVE
AUTOMATIC
AIR PURGER
TEMP. & PRESS.
INDICATOR
OU LETT
⚠⚠
o
45 48 2 to 4 70 135 97 67
65 72 3 to 5 90 135 120 90
45 48 3 to 5 100 178 200 170
65 72 5 to 7 125 178 209 179
* First hour rang (in gallons per hour) is the amount of hot water a fully heated tank can deliver in one hour.
** Recovery is the volume (in gallons) that can be heated in one hour from inial water temperature on the cold line to
the temperature rise specied by the manufacturer. Enertech uses a 60
O
F temperature rise.
*** Storage required to compare to the EAV, using am electric water heater with two interlocked 4,500 Wa elements or
a gas water heater with 40,000 Btuh input.
Capacies shown are at 47°F Outdoor Air Temp (OAT). At colder temperatures, capacies are lower. For example, at 10°F, the
capacity is approximately 1/2 of the capacity at 47°F. A backup water heater is recommended.
A
55.00 50.50 9.50 5.75 4.00 22.00 235 lbs
67.00 60.50 9.50 6.50 4.00 24.00 250 lbs
