Enertech EAV060 - Piping Diagram - Piping between Outdoor Unit and Indoor Module

Enertech Global 
EAV - EME/EMD Rev. A Models
Installaon and Operaons Manual
PEX OR COPPER
TUBING
INDOOR
MODULE
OUTDOOR
UNIT
STAINLESS STEEL
FLEX TUBING KIT
NOT SHOWN:
PIPING INSULATION
NOT SHOWN:
OPTIONAL SUPPORT
STAND FOR AREAS WITH
SNOW ACCUMULATION
SUGGESTED
12” OFF FLOOR
MANUAL
AIR VENT
OUTSIDE
WALL



Pipe Sleeve
Foundation or Wall
Piping To/From
Outdoor Unit
End of Pipe Sleeve Must Be
a Minimum of 1” Beyond Wall
Fernco Fitting
⚠⚠









