Enertech EAV060 - Field Wiring; Electrical Connections

Enertech Global 
EAV - EME/EMD Rev. A Models
Installaon and Operaons Manual

• The heat pump must be connected by a qualied technician.
• EAV does not include a circuit breaker on the incoming
power supply. The heat pump’s supply cable must be
connected to a circuit breaker. A disconnect must be
installed near the unit per local code requirements.
• The roung of cables for heavy current and signals should
be made out through the cable openings on the heat
pump’s right-hand side, seen from the front.
• The communicaon cable must be a shielded cable and be
connected between EAV terminal block X22 and the indoor
module/control module
• Connect the ushing pump to the indoor module/control
module.
 Electrical installaon and service must be carried out by a
qualied technician. Disconnect power at the disconnect before
carrying out any servicing. Electrical installaon and wiring must
be carried out in accordance with local code.
 Check the connecons, main voltage and low voltage
before the machine is started, to prevent damage to the air/
water heat pump electronics.



