Installation and Operation Manual - COMTEC
®
6000 Software Overview and Explanations
Doc.-ID: COM6000_11022020_EN 31
4.3 System Checks
O
2
+ CO
e
Sensor checks
Source: Test air
O
2
sensor .. mV = .. %
CO
e
sensor .. mV = .. ppm
Flow rate .. l/h
Source: Test gas
O
2
sensor ... mV =... %
CO
e
sensor ... mV =... ppm
Flow rate (3 bar max) ... l/h
Source: Process
O
2
sensor .. mV = .. %
CO
e
sensor .. mV = .. ppm
Check mA outputs
Set mA output 17A/B (mA)
Set mA output 34A/B (mA)
Check relay outputs
Relay contact at 18A/B (opened / closed)
Relay contact at 19A/B (opened / closed)
Relay contact at 20A/B (opened / closed)
Relay contact at 21A/B (opened / closed)
Relay contact at 22A/B (opened / closed)
Check digital inputs
Input status at 25A/B
Input status at 27A/B
4.4 CAL MENU
CAL MENU
1 point calibration, O
2
2 point calibration, O
2
1 point calibration, CO
e
2 point calibration, CO
e
1 point calibration, O
2
+ CO
e
2 point calibration, O
2
+ CO
e
