1 System Description
1.1 System Overview of the COMTEC 6000
Figure 1 - System overview of the COMTEC 6000 for flue gas temperatures of up to 600° C
Electronic unit SME5 / IP66
Safe Area - Max. ambient temp.: -20 °C to +55 °C
(-4 °F to + 131 °F)
InSitu measuring probe / IP65
Safe Area - Max. ambient temp.: -40°C to +80°C
(-4 °F to + 167 °F)
Pneumatic cable Duct / combustion chamber
O
2
probe signal cable Flue gas direction – max. flue gas temperature 500 °C
Counter flange Manufacturer supply
Isolation: Customer Customer supply
Duct wall Test gas in
Power supply
Instrument air in
Output signals (analog and digital)
Test air in (only with pump version of electronics)
