Enotec COMTEC 6000 - 5.10 Replacing the COe Sensor

Installation and Operation Manual - COMTEC
®
6000 Service and Maintenance
Doc.-ID: COM6000_11022020_EN 41
5.10 Replacing the CO
e
Sensor
Caution
Failure to observe this information may destroy the new replacement CO
e
sensor.
Disable the CO
e
Sensor (via the software) SYS-MENU  System Configuration  Set CO
e
measure-
ment OFF
Switch off the power supply of the analyzer system.
Disconnect the CO
e
sensor wires at the
probe terminal block no. 11-14.
Figure 36 - Connection of the CO
e
sensor
Unscrew and remove the cap nut
.
Loosen the clamping ring , the O-ring
and the retainer ring
.
Pull the CO
e
sensor out of the probe.
Take care: The COe sensor may be hot
Figure 37 - Remove the CO
e
sensor
1
2
34
