Enotec COMTEC 6000 - Service and Maintenance; 5.1 Exchange Fuses

Service and Maintenance Installation and Operation Manual - COMTEC
®
6000
34 Doc.-ID: COM6000_11022020_EN
5 Service and Maintenance
5.1 Exchange fuses
Warning
De-energize the system first!
Abb. 26 Position of the fuses
fuse system voltage ampere nominal voltage characteristic Size
F3 115 / 230 V AC 0.5 A 250 V AC T / L 5x20 mm
F4 115 / 230 V AC 0.5 A 250 V AC T / L 5x20 mm
F5 115 / 230 V AC 1.0 A 250 V AC M / L 5x20 mm
F1 230 V AC 2.0 A 250 V AC T / H 5x20 mm
F1 115 V AC 4.0 A 250 V AC T / H 5x20 mm
F2 115 / 230 V AC 4.0 A 250 V AC M / H 5x20 mm
