ENSONIQ DP/4+ User Manual

Section 2 — Algorithms
28 ENSONIQ DP/4+ Reference Manual
EQ - DDL - WITH LFO
EQ-DDL-withLFO features a parametric EQ and a stereo digital delay (similar to Dual Delay)
that provides LFO modulation of a wide range of delays. This algorithm sounds great with an
electric piano, but try it with any source!
EQ-DDL-withLFO Signal Routing
Right
EQ
R
Right
Delay
EQ
L
Main
Outputs
Left
Left
Delay
Cross
Regen
Input Level Trim
LFO
Right
Delay
Input
(On/Off)
Regen
Regen
Damping
(LPF)
Damping
(LPF)
Output Level
01 — Mix
02 — Volume
See the descriptions under the Mix and Volume Parameters, in the beginning of this section.
03 — DDL+LFO Left Delay Time Range: 0 to 845 ms
Determines the amount of time between the input signal and the left delay output.
04 — DDL+LFO Right Delay Time Range: 0 to 845 ms
Determines the amount of time between the input signal and the right delay output. Set this
differently from parameter 03 to achieve syncopated repeats.
05 — DDL+LFO LFO Rate Range: 00 to 99
Controls the rate of pitch modulation which is the LFO. To achieve a chorusing effect, this rate
must be very slow.
06 — DDL+LFO LFO Width Range: 00 to 99
Controls the excursion of pitch modulation. Since the rate is usually very slow, then the width is
usually large.
07 — Left/Right LFO Range: Out-of-Phase or In-Phase
When this parameter is In-Phase, the left and right choruses will modulate their detunes together.
When set to Out-of-Phase, the detune on the left channel will go up while the detune on the right
will go down.
