Overview
SecureStack C3 Installation Guide 1-3
C3G124-48P Stackable Switch
TheC3G124‐48P(Figure 1‐2)hasseveraltypesoffrontpanelportconnections,which
include:
•Forty‐eightRJ45ports(10/100/1000Mbps,1000BASE‐Tcopperports)thatalso
supportPoEforconnectionstonetwork803.2afcompliantPDs(powereddevices).
•FourSFPslotsforoptionalSmallFormPluggable(SFP)Mini‐GBICsfor1000BASE
‐SX/
LXfiber‐opticconnectionsand1000BASE‐Tcopperconnections.
•Rearpanelconnectorsforhigh‐speedconnectionsinastackconfiguration.
•RearpanelRedundantPowerSupplyconnectorusedtoconnecttoaPoERedundant
PowerSupply(C2RPS‐POE).TheswitchconnectstotheC2RPS‐POEusinga
C2RPS‐POEcable.
The10/100/1000 Mbps
fixedfrontpanelportscanoperateineitherhalf‐duplexorfull‐
duplexmode,asdeterminedbyAuto‐Negotiation.
Note: The Mini-GBIC ports cannot be active simultaneously with their corresponding
10/100/1000BASE-T ports. For example, if SFP port 48 establishes a link first on the
C3G124-48P, the 10/100/1000BASE-T built-in RJ45 port 48 is not available and
vice-versa.
Caution: The C3G124-24P and C3G124-48P are PoE-compliant devices. Do not connect
a SecureStack Redundant Power System (C2RPS-SYS) to the power connector.
Otherwise, damage to the device may result.
Precaución: Los dispositivos C3G124-24P y C3G124-48P cumplen con el estándar PoE
(power over ethernet). No conecte una fuente de poder redundante (RPS) SecureStack
(C2RPS-SYS) al cable de corriente. De lo contrario, el dispositivo puede dañarse.
