Gigabit Ethernet Specifications
A-4 Specifications
Gigabit Ethernet Specifications
ThefollowingspecificationsfortheMini‐GBICsshowninTable A‐3throughTable A‐10
meetorexceedtheIEEE802.3z‐1998standard.
MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)
MGBIC-02 Provides one RJ45 copper connection that is compliant with the
1000BASE-T standard RJ45 connector.
Table A-2 Mini-GBIC Input/Output Port Specifications (continued)
Item Specification
Table A-3 MGBIC-LC01/MGBIC-MT01 Optical Specifications
Item 62.5 µm MMF 50 µm MMF
Transmit Power (minimum) -9.5 dBm -9.5 dBm
Receive Sensitivity -17 dBm -17 dBm
Link Power Budget 7.5 dBm 7.5 dBm
Table A-4 MGBIC-LC01/MGBIC-MT01 Operating Range
Item
Modal Bandwidth @
850 nm
Range
62.5 µm MMF 160 MHz/km 2-220 Meters
62.5 µm MMF 200 MHz/km 2-275 Meters
50 µm MMF 400 MHz/km 2-500 Meters
50 µm MMF 500 MHz/km 2-550 Meters
