Connecting to the Network
3-22 Hardware Installation
Figure 3-12 Connecting to a Modem
Connecting to the Network
Thefollowingprocedurescoverthecableconnectionsfromthenetworkorotherdevices
totheswitchRJ45portsoranyinstalledoptionalMiniGBIC.
ConnectingUTPCablesonpage 322
ConnectingFiberOpticCablestoMTRJPortsonpage 326
ConnectingFiberOpticCablestoLCPortsonpage 3
28
Connecting UTP Cables
ThefixedRJ45frontpanelportsare10/100/1000 Mbpsportsandhaveinternalcrossovers.
Whenconnectingaworkstationtotheseports,useastraig ht throughcable.When
connectingnetworkingdevicestotheseports,suchasabridge,repeater,orrouter,usea
crossovercable.
Toconnecttwistedpairsegmentstothe
switch,refertoFigure 313andproceedas
follows:
1. Ensurethatthedevicetobeconnectedattheotherendofthesegmentis
powered ON.
2. ConnectthetwistedpairsegmenttotheswitchbyinsertingtheRJ45connectoronthe
twistedpairsegmentintothedesiredRJ45port(forexample,Port8).
1 DB9 female cable connector 4 DB25 male connector 7 PC with VT emulation application
2 Serial interface cable 5 Local modem
3 DB9 male Console port 6 Remote modem
Note: All fixed RJ45 front panel ports support Category 5 Unshielded Twisted Pair (UTP)
cabling with an impedance between 85 and 111 ohms. Category 3 cable may be used if
the connection is going to be used only for 10 Mbps.
