Control Panel for AL-M320DN/AL-M310DN
1.
u Up button
Press to scroll the items on the control panel menus.
2.
l Left button Press to go back to the previous menu, or press to show the help if l Press for
help is displayed.
3.
OK button
Press to set the menu, item or setting.
When the error light is flashing, pressing this button clears the error and switches the
printer to ready status.
4.
d Down button
Press to scroll the items on the control panel menus.
5.
Pause/Release button
Press once to pause. Press again to recover from pause. While paused, the following
operations are available on the control panel.
❏ Canceling the current print job or stored print jobs.
See “Cancelling a Print Job” on page 62.
❏ Interrupting print jobs to print a stored print job.
❏ Ejecting a paper (Form Feed) by holding down the OK button for more than 2
seconds.
6.
r Right button
Press to go to the next menu, item or setting.
7.
Wakeup/Sleep button
Press to switch the status between available for printing and saving power.
This button lights up when the printer is in the sleep mode (the deep sleep mode).
This button blinks when the printer enters the power off mode, which saves power
because almost all functions are not available.
For more details about the power off mode, see “Energy Saver Menu” on
page 25.
8. LCD panel Displays printer status messages and control panel menu settings.
9.
Ready light
On when the printer is ready, indicating that the printer is ready to receive and print
data.
Off when the printer is not ready, or in the sleep mode.
10.
Error light (Orange)
On or flashes when an error has occurred.
Pressing the OK button or Auto Cont setting in the Setup Menu clears the errors
that are flashing.
AL-M320DN/AL-M310DN/AL-M220DN User's Guide
Getting to Know Your Printer
14
