Item Explanation
Binary Specifies the data format. Select On for the Binary data and select Off for the ASCII data.
Note:
Binary can only be used with network connection. To use the Binary data, make sure
your application supports Binary data and that SEND CTRL-D Before Each Job and
SEND CTRL-D After Each Job are set to No. When this setting is set to On, you cannot
use TBCP (Tagged binary communication protocol) in the printer driver settings.
Settings (default in bold):
Off, On
PDF Page Size Specifies the paper size when you send the PDF file directory from a computer or some
other device. If Auto is selected, the paper size is determined based on the size of the first
page that is printed.
Settings (default in bold):
Auto, A4, A5, A6, B5, LT, HLT, LGL, GLT, GLG, EXE, F4, MON, C10, DL, C5, C6, IB5
ESCP2 Menu
Item Explanation
Font Selects the font.
Settings (default in bold):
Courier, Prestige, Roman, Sans serif, Roman T, Orator S, Sans H, Script, OCR A, OCR B
Pitch Selects the pitch (the horizontal spacing) of the font in fixed pitch, measured in cpi
(characters per inch). You can also choose proportional spacing.
Settings (default in bold):
10cpi, 12cpi, 15cpi, Prop.
Condensed Turns condensed printing on or off.
Settings (default in bold):
Off, On
T.Margin Sets the distance from the top of the page to the baseline of the first printable line. The
distance is measured in inches. The smaller the value, the closer the printable line is to the
top.
Settings (default in bold):
0.40 ... 0.50 ... 1.50 inch in 0.05-inch increments
Text Sets the page length in lines. For this option, a line is assumed to be 1 pica (1/6 inch). If you
change the Orientation, Page Size, or T.Margin settings, the page length setting
automatically returns to the default for each paper size.
Settings (default in bold):
1 ... 66 Lines
AL-M320DN/AL-M310DN/AL-M220DN User's Guide
Getting to Know Your Printer
33
