Epson EB-PU2220B User Manual

Extended Menu
100
a
When you set Schedule Protection to On in the Password Protection
screen, you cannot change the time and date settings. Set Schedule
Protection to Off first.
Lens Calibration
s Extended > Operation > Lens Calibration
You can view information about the lens currently in use.
It takes up to approximately 100 seconds. When calibration is finished, the
lens returns to the same position it was in before calibration.
The following lenses return to the standard position.
• ELPLX02S
• ELPLX02WS
A/V Settings
s Extended > A/V Settings
You can select to output audio and video to an external device when the
projector is in standby mode (when the power is off).
Select Always On to output audio and images to external devices when the
projector does not project any images.
a
• Available only when Quick Startup is set to Off, and Auto Power
On is set to Off or Computer.
• When set to Always On, you can move the lens position to the home
position even if the projector is in standby mode.
• When set to Always On, and Control Communication is set to On,
communication from the HDBaseT port is enabled even if the
projector is in standby mode.
Standby Mode
s Extended > Standby Mode
Set to Communication On to monitor and control the projector over a
network.
a
• Set A/V Output to While Projecting first.
• Available only when Auto Power On is set to Off or Computer.
• Available only when USB Power is set to On While Projecting.
HDBaseT
s Extended > HDBaseT
You can select the communication settings for connections to an HDBaseT
transmitter or switcher.
Control Communications
You can enable or disable communication from the Ethernet and serial
ports on the HDBaseT transmitter or switcher; set to On to disable the
projector's LAN, RS-232C, and Remote ports.
Extron XTP
Set to On when you connect an Extron XTP transmitter or switcher to the
HDBaseT ports. See the following Extron Web site for more details on the
XTP system.
http://www.extron.com/
a
• Control Communications is only displayed when Extron XTP is set
to Off.
• When Extron XTP is set to On, the cooling fans may run even in
standby status. This is not a malfunction.

Epson EB-PU2220B Specifications

General

Matrix type	3-panel (p-Si TFT active)
Number of colors	1.07 billion colors
Native aspect ratio	-
Projection technology	3LCD
Supported aspect ratios	4:3, 16:10, 16:9
Contrast ratio (typical)	2500000:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, vertical	±45 °
Keystone correction, horizontal	±30 °
Light source type	Laser
Service life of light source	20000 h
Focus	Auto
Throw ratio	1.57 – 2.56
Optical zoom	1.6 x
Focal length range	14.8 – 17.7 mm
Aperture range (F-F)	2 - 2.1
Interchangeable lens	Yes
Vertical lens shift range	-60 - 60 %
Horizontal lens shift range	-18 - 18 %
Number of optional lenses supported	9
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160i, 2160p
Supported graphics resolutions	640 x 480 (VGA), 720 x 576, 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160, 4096 x 2160
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 2.0 Type-A ports quantity	2
Noise level	45 dB
HDCP version	2.3
Projection modes	Ceiling, Front, Rear
Noise level (economic mode)	37 dB
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	1301 W
Power consumption (economy mode)	899 W
Operating temperature (T-T)	0 - 50 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	493 mm
Width	587 mm
Height	218 mm
Weight	24400 g
