Settings Menu
83
Memory
You can save the shape of an image you have adjusted and load it when
needed.
a
You can also open the Geometry Correction screen using the
[Geometry] button on the control panel or remote control.
You can also open the Memory screen using the [Memory] button
on the remote control.
Split Screen
s Settings > Split Screen
You can simultaneously project two images from different image sources.
Screen Size
Select the screen size.
a
Depending on the video signals that are input, the images on the left
and right may not appear to be the same size even if you select
Equal.
Source
Select the input source.
a
The following input source combinations cannot be projected on
a split screen.
Computer and LAN
DVI-D and HDMI
Computer and SDI (EBPU2220B)
LAN and SDI (EBPU2220B)
Input signals with a horizontal resolution exceeding 1920 are not
supported.
Swap Screens
You can swap images that are being projected on the left and right.
Audio Source
Select the screen from which you want to hear audio.
When you select Auto, audio is output from the enlarged screen. If the
screen size is set to Equal, audio is output from the screen on the left.
a
While using the split screen feature, other projector features may not
be available and some settings may be automatically applied to all
images.
You cannot perform split screen projection when the Content
Playback setting is set to On in the projector's Settings menu.
You can also open the Split Screen Setup screen using the [Split]
button on the remote control.
gg Related Links
"Split Screen Projection Restrictions" p.83
Split Screen Projection Restrictions
Operating restrictions
The following operations cannot be performed during split screen projection.
Setting the projector's menu
E-Zoom
Switching the aspect mode (the aspect mode is set to Normal)
Operations using the [User] button on the remote control
Image restrictions
If you make adjustments such as Brightness, Contrast, Color Saturation,
Tint, and Sharpness in the projector's Image menu, you can apply them
only to the image on the left. Default adjustments are applied to the image
on the right. Adjustments that affect the entire projected image such as
Color Mode and Color Temp. are applied for both left and right images.
Even if you make adjustments for Noise Reduction and Deinterlacing in
the projector's Image menu, Noise Reduction is set to 0 and Deinterlacing
is set to Off for the image on the right.
s Image > Image Enhancement > Noise Reduction
