Epson EB-PU2220B User Manual

Contents
6
SNMP ............................................................................................................................................... 113
Trap IP Address 1/Trap IP Address 2.................................................................................... 113
Community Name ...................................................................................................................... 114
PJLink Notification...................................................................................................................... 114
Notified IP Address..................................................................................................................... 114
Command Communication..................................................................................................... 114
Secure HTTP .................................................................................................................................. 114
Web Server Certificate............................................................................................................... 114
Web API Settings......................................................................................................................... 114
Priority Gateway .......................................................................................................................... 115
PJLink............................................................................................................................................... 115
AMX Device Discovery .............................................................................................................. 115
Crestron Connected................................................................................................................... 115
Art-Net............................................................................................................................................. 115
Message Broadcasting .............................................................................................................. 115
Reset (Network menu) .............................................................................................................. 116
Info Menu........................................................................................ 117
Projector Info................................................................................................................................ 117
Event ID Code List................................................................................................................. 117
Light Source Info......................................................................................................................... 118
Version ............................................................................................................................................ 118
Status Information...................................................................................................................... 118
Voltage Warning Info ................................................................................................................ 119
Temp Warning Info .................................................................................................................... 119
Power On/Off History ................................................................................................................ 119
Reset Menu ..................................................................................... 120
Reset All Memories..................................................................................................................... 120
Refresh Mode................................................................................................................................ 120
Light Source Calibration........................................................................................................... 120
Reset All Config............................................................................................................................ 121
Reset All (Factory Default) ....................................................................................................... 121
Adjusting Projector Features 123
Multi-Projection Features ............................................................. 124
Procedure Overview .................................................................................................................. 124
Preparing for Multi-Projection ............................................................................................... 124
Initializing Projectors ........................................................................................................... 124
Assigning a Master Projector............................................................................................ 125
Calibrating Projectors.......................................................................................................... 125
Installing Projectors.............................................................................................................. 125
Performing Rough Image Adjustments........................................................................ 125
Connecting Projectors to a Network ............................................................................. 126
Image Composition.................................................................................................................... 126
Tiling Using the Epson Projector Professional Tool Software.............................. 126
Tiling Using the Projector's Menu................................................................................... 127
Stacking Using the Epson Projector Professional Tool Software........................ 131
Stacking Using the Projector's Menu............................................................................. 131
Adjusting Colors.......................................................................................................................... 132
External Camera Usage ................................................................. 133
Monitoring and Controlling the Projector 134
Projector Monitoring and Control Options................................. 135
Epson Projector Management ............................................................................................... 135
Epson Web Control .................................................................................................................... 135
SNMP ............................................................................................................................................... 135
ESC/VP21 Commands .............................................................................................................. 135
ESC/VP.net Commands............................................................................................................. 136
PJLink............................................................................................................................................... 136
Art-Net............................................................................................................................................. 136
Crestron Connected Support ................................................................................................. 136
Web API .......................................................................................................................................... 137
Accessing a Networked Projector Using a Web Browser........... 138
Web Control Options................................................................................................................. 139

Epson EB-PU2220B Specifications

General

Matrix type	3-panel (p-Si TFT active)
Number of colors	1.07 billion colors
Native aspect ratio	-
Projection technology	3LCD
Supported aspect ratios	4:3, 16:10, 16:9
Contrast ratio (typical)	2500000:1
Screen size compatibility	- \
Projector native resolution	WUXGA (1920x1200)
Keystone correction, vertical	±45 °
Keystone correction, horizontal	±30 °
Light source type	Laser
Service life of light source	20000 h
Focus	Auto
Throw ratio	1.57 – 2.56
Optical zoom	1.6 x
Focal length range	14.8 – 17.7 mm
Aperture range (F-F)	2 - 2.1
Interchangeable lens	Yes
Vertical lens shift range	-60 - 60 %
Horizontal lens shift range	-18 - 18 %
Number of optional lenses supported	9
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 2160i, 2160p
Supported graphics resolutions	640 x 480 (VGA), 720 x 576, 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 3840 x 2160, 4096 x 2160
HDMI connector type	Full-size
Serial interface type	RS-232C
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 2.0 Type-A ports quantity	2
Noise level	45 dB
HDCP version	2.3
Projection modes	Ceiling, Front, Rear
Noise level (economic mode)	37 dB
Product type	Large venue projector
Product color	Black
Market positioning	Presentation
Cable lock slot type	Kensington
Power source	AC
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	2 W
Power consumption (typical)	1301 W
Power consumption (economy mode)	899 W
Operating temperature (T-T)	0 - 50 °C
Sustainability certificates	RoHS

Weight and Dimensions

Depth	493 mm
Width	587 mm
Height	218 mm
Weight	24400 g
