Epson EB-W06 Service Manual

EB-E01 series Troubleshooting INTERNAL USE ONLY
SEIKO EPSON 56 Revision A
*1 EB-FH52/992F, EH-TW750
*2 EB-FH52/992F/W52, EH-TW750
*3 EB-E01/X06/W06/E10/X51/W51/W52
*4 EB-FH52/972/982W/992F/118, PL 119W
*5 EB-FH06/E20/X49/W49, EH-TW740/TW750
CN2200 Auto Iris Assy Auto Iris Auto Iris Error
The power can turn on and Power LED lights blue. When pressing the power button,
initialization starts but instantly the projector changes to the Auto Iris Error mode. The
error message in Auto Iris is displayed on the screen, and it advises the user to turn off
the power and to contact the Epson Service. When pressing the power button, the LEDs
indicate the warning and after a certain period of cooling, the projector turns into the
abnormal stand-by status. The LED Indicator’s warning display continues until
unplugging the AC cable.
P.60
CN700*
3
Speaker (2W)
--- ---
When pressing the power button, initialization starts normally and the projection starts.
However, no sound is output from the speaker even if the audio input is applied. Audio
controller on screen display appears, but no sound is output from the speaker even if
the audio input is applied.
P.62
CN701*
4
Speaker (16W)
CN702*
5
Speaker (5W)
Connector
No.
Destination
Error Information
Phenomenon Reference
Error Name/
Device Name
Name

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
