Epson EB-W06 Service Manual

EB-E01 series Troubleshooting INTERNAL USE ONLY
SEIKO EPSON 57 Revision A
SW Board
* Not for EB-E01/E10
Connector
No.
Destination
Error Information
Phenomenon Reference
Error Name/
Device Name
Name
CN1 MA Board (CN1400) Cover Open Lamp cover open error
The power cannot be turned on with the operation panel. However, the power can be
turned on with the remote controller. When the power is turned on, the fan rotates at
high speed and turns off after a short while. Then the machine goes into abnormal
stand-by mode after displaying Lamp Cover Open Error.
P.62
CN2* H Key ASSY --- ---
Operates normally after the power turns on, but the lateral strain of the projected image
cannot be corrected.
P.62
CN3* Lens Cover SW SH Shutter error
The power can turn on and Power LED lights blue. When pressing the power button,
initialization starts normally and the projection starts. But the lamp does not turn off
even when the shutter is closed, and the AV mute does not function. (However, AV
mute on the remote controller works normally)
Note) Please note that this error may cause troubles such as deformation of the shutter
if it is kept closed.
P.59
CN4 Lamp Cover SW Cover Open Lamp cover open error
When the power is turned on, the machine goes into abnormal stand-by mode after
displaying Lamp Cover Open Error.
P.59

Epson EB-W06 Specifications

General

Contrast Ratio	16, 000:1
Weight	2.5 kg
Projection System	3LCD
Aspect Ratio	16:10
Projection Ratio	1.30 - 1.56:1
Screen Size	33 inches - 320 inches
Projection Lens F Number	1.49 - 1.72
Projection Lens Focal Length	16.9 - 20.28 mm
Projection Lens Focus	Manual
Security	Kensington lock, Password protection
3D	No
Resolution	WXGA (1280 x 800)
Brightness	3700 lumens
Lamp Life	12000 hours (Eco)
Keystone Correction	Vertical: ±30 degrees, Horizontal: ±30 degrees
Connectivity	HDMI, VGA, USB
LCD Panel	0.59-inch with MLA (D10)
Lamp	UHE, 210 W
Zoom	Factor: 1.2
Noise Level	37 dB (Normal)
Dimensions	302 x 237 x 82 mm (Width x Depth x Height)
Power Consumption	0.3 W (Standby)
